Introduction to Electromagnetic Induction
Electromagnetic induction class 12 notes explain how a changing magnetic flux through a circuit induces an emf (ε = −dΦ/dt, Faraday’s law), why the induced current opposes the change that causes it (Lenz’s law), how a moving rod develops a motional emf ε = Blv, how coils show self and mutual inductance, and how an AC generator uses a rotating coil to produce ε = NBAω sin ωt.
- Core ideas: experiments of Faraday and Henry, magnetic flux, Faraday’s law, Lenz’s law and energy conservation, motional emf, mutual and self inductance, energy stored in an inductor, AC generator
- Key formulas: Φ = BA cos θ, ε = −N dΦ/dt, ε = Blv, ε = −L dI/dt, ε = −M dI/dt, L = μ₀n²Al, U = ½LI², ε = NBAω sin ωt
- Most tested in NEET: induced emf from changing flux, direction by Lenz’s law, motional emf of rods, inductance of solenoids, peak emf of a generator
- Free PDF: full chapter notes in our study app (link below)
Oersted showed that an electric current produces a magnetic field. Around 1830, Michael Faraday in England and Joseph Henry in the USA showed the reverse: a changing magnetic field produces an electric current. The phenomenon in which an electric current is generated by a varying magnetic field is called electromagnetic induction. It is the principle behind generators in power stations and transformers that bring electricity to our homes.
Experiments of Faraday and Henry
- Magnet and coil: pushing the north pole of a bar magnet towards a coil connected to a galvanometer deflects the pointer; pulling it away deflects it the other way. There is no deflection when the magnet is held still. The faster the magnet moves, the larger the deflection.
- Two coils: a steady current in one coil and a galvanometer on a second coil show a deflection only when the coils move relative to each other.
- Pressing a key: with two stationary coils, the galvanometer deflects momentarily when the current in the first coil is switched on or off, and not while the current is steady. An iron rod inserted along the axis increases the deflection dramatically.
Key insight: electromagnetic induction class 12 notes start from one observation – an emf appears only while the magnetic flux through the circuit is changing.
Understanding Magnetic Flux
In electromagnetic induction class 12 notes, magnetic flux through a plane surface of area A in a uniform magnetic field B depends on the orientation of the surface, just like electric flux.
Φ_B = B · A = BA cos θ
θ = angle between B and the normal to the area
Non-uniform field: Φ_B = Σ B · dA
- Magnetic flux is a scalar quantity, even though it is the product of two vectors.
- The SI unit is the weber (Wb): 1 Wb = 1 T m².
- Flux is maximum (BA) when the field is perpendicular to the surface (θ = 0°) and zero when the field is parallel to it (θ = 90°).
Flux can change in three ways: by changing B, by changing the area A, or by changing the angle θ (as in a rotating coil). Identify which one is changing before choosing a formula.
Key insight: electromagnetic induction class 12 notes measure θ from the normal to the area, not from the surface – a frequent source of sign and cos/sin errors.
Faraday’s Law of Induction
Faraday’s experiments led to a single law, the backbone of electromagnetic induction class 12 notes:
The magnitude of the induced emf in a circuit is equal to the time rate of change of magnetic flux through the circuit.
ε = −dΦ_B / dt
Closely wound coil of N turns: ε = −N dΦ_B / dt
In electromagnetic induction class 12 notes, the emf lasts only as long as the flux keeps changing. Increasing the number of turns increases the induced emf, which is why coils with many turns are used in induction experiments and devices.
The negative sign is not just a mathematical detail. It shows the direction of the induced emf, as given by Lenz’s law. In magnitude-only numericals you can drop it, but never in direction questions.
Key insight: electromagnetic induction class 12 notes give the induced emf as ε = −N dΦ/dt, so the emf depends on how fast the flux changes, not on the flux itself.
Lenz’s Law and Conservation of Energy
In 1834, the German physicist Heinrich Friedrich Lenz deduced a rule for the direction of the induced emf. In electromagnetic induction class 12 notes, Lenz’s law states:
The polarity of the induced emf is such that it tends to produce a current which opposes the change in magnetic flux that produced it.
In electromagnetic induction class 12 notes, when the north pole of a bar magnet is pushed towards a closed coil, the flux through the coil increases. The induced current flows so that the face of the coil nearest the magnet becomes a north pole, repelling the approaching magnet. When the magnet is pulled away, the near face becomes a south pole, attracting the magnet and opposing its removal.
Lenz’s Law and Energy
Lenz’s law is consistent with the law of conservation of energy. If the induced current aided the change in flux, the magnet would be pulled in faster and faster without any external work, creating energy from nothing. Instead, we must do mechanical work against the opposing force to move the magnet, and this work appears as electrical energy, which is finally dissipated as Joule heat in the coil.
If the coil is open (not a closed circuit), an emf is still induced across its ends, but no current flows, so there is no opposing force on the magnet.
Key insight: electromagnetic induction class 12 notes justify Lenz’s law by energy conservation – the induced current always opposes the cause, so external work is needed.
Motional Electromotive Force
Consider a straight conductor of length l moving with velocity v on a pair of rails, in a uniform magnetic field B perpendicular to the plane. As the rod moves a distance x, the area of the circuit changes, so the flux changes and an emf is induced. The emf induced by the motion of a conductor through a magnetic field is called motional emf.
Φ_B = Blx → ε = −dΦ_B/dt = −Bl (dx/dt) = Blv (magnitude)
Rod of length l rotating about one end with angular speed ω: ε = ½ Bωl²
The same result can be explained using the Lorentz force on the free charges in the rod. Each charge q moving with the rod feels a force qvB along the rod, which pushes charges to one end and creates the emf. In electromagnetic induction class 12 notes, this shows that motional emf comes from the magnetic force on moving charges.
Use Fleming’s right-hand rule for direction: stretch the thumb, forefinger and middle finger of the right hand mutually perpendicular. If the forefinger points along the magnetic field and the thumb along the motion of the conductor, the middle finger points along the induced current.
Key insight: electromagnetic induction class 12 notes give ε = Blv for a sliding rod and ε = ½Bωl² for a rotating rod – both come from the changing area swept in the field.
Read the topic? Try the NEET previous year questions from Electromagnetic Induction next, with answers.
Practice Electromagnetic Induction PYQsMutual and Self Inductance
An electric current can be induced in a coil by flux change produced by another coil nearby, or by flux change produced by the same coil. In electromagnetic induction class 12 notes, the flux linkage is proportional to the current, and the constant of proportionality is the inductance. Its SI unit is the henry (H).
Mutual Inductance
When a changing current in one coil induces an emf in a nearby coil, the phenomenon is mutual induction. For two long coaxial solenoids of length l, with the inner one of radius r₁:
N₁Φ₁ = M I₂ | ε₁ = −M dI₂/dt
Coaxial solenoids: M₁₂ = M₂₁ = μ₀ n₁ n₂ π r₁² l
With a medium of relative permeability μ_r: M = μ_r μ₀ n₁ n₂ π r₁² l
Mutual inductance depends on the geometry of the two coils, their separation and relative orientation, and the medium between them. A transformer works on mutual induction.
Self Inductance
When the current in a coil changes, the flux through the same coil changes, inducing an emf in it that opposes the change in current. This is self induction, and the induced emf is called back emf. Self inductance plays the role of inertia in circuits: it is the electromagnetic analogue of mass in mechanics.
NΦ_B = LI | ε = −L dI/dt
Long solenoid: L = μ₀ n² A l = μ₀ N² A / l (n = N/l)
With a core of relative permeability μ_r: L = μ_r μ₀ n² A l
Energy Stored in an Inductor
In electromagnetic induction class 12 notes, work must be done against the back emf to establish a current in an inductor. This energy is stored in its magnetic field, just as a capacitor stores energy in its electric field.
U = ½ L I²
This is similar to kinetic energy ½mv², with L playing the role of mass m and I the role of velocity v.
Key insight: electromagnetic induction class 12 notes treat inductance as electrical inertia – L = μ₀n²Al for a solenoid and U = ½LI² for stored energy.
AC Generator and Transformer
The AC generator, developed by Nikola Tesla among others, converts mechanical energy into electrical energy. In electromagnetic induction class 12 notes, a coil (armature) of N turns and area A rotates with constant angular speed ω in a uniform magnetic field B. The angle between B and the normal to the coil at time t is θ = ωt, so the flux keeps changing.
Φ_B = BA cos ωt
ε = −N dΦ_B/dt = NBAω sin ωt = ε₀ sin ωt
Peak emf: ε₀ = NBAω | ω = 2πν
- The emf is maximum when the plane of the coil is parallel to the field (sin ωt = ±1) and zero when the plane is perpendicular to it.
- The direction of the current changes periodically, so the current is alternating current (AC).
- In India, the frequency of the mains AC supply is 50 Hz. In commercial generators, the mechanical energy comes from water falling from a height (hydroelectric) or from steam produced by burning coal or other fuels (thermal).
Transformer
A transformer changes an alternating voltage from one value to another. It works on mutual induction and is covered in detail in the Alternating Current chapter.
| Feature | Step-up transformer | Step-down transformer |
|---|---|---|
| Turns ratio | Ns > Np | Ns < Np |
| Voltage | Vs > Vp | Vs < Vp |
| Current | Is < Ip | Is > Ip |
| Application | At power stations, before long-distance transmission | Near homes and for household appliances |
Ideal transformer: V_s / V_p = N_s / N_p = I_p / I_s
A transformer cannot change a steady DC voltage, because a constant current produces no change in flux.
Key insight: electromagnetic induction class 12 notes give the generator’s peak emf as NBAω – doubling the speed of rotation doubles both the peak emf and the frequency.
Eddy Currents
Eddy currents are not part of the current NEET syllabus or the rationalised NCERT chapter. They are kept here briefly for background, so give them the least revision time.
When bulk pieces of conductors are subjected to changing magnetic flux, circulating currents called eddy currents are induced throughout their volume. They cause heating and energy loss, which is why transformer cores are laminated with thin, insulated sheets. They are also used constructively in magnetic braking in trains, induction furnaces for melting metals, and electric power meters.
Key insight: for electromagnetic induction class 12 notes, eddy currents are background only, so give them the least revision time.
Numerical Strategy and Common Mistakes
Most marks from electromagnetic induction class 12 notes come from short numericals. Follow this workflow:
- Identify the variable: is B, A or θ changing?
- Check units: B in tesla, area in m², time in seconds.
- Select the formula: ε = N ΔΦ/Δt for changing flux, ε = Blv for straight rods, ε = ½Bωl² for rotating rods, ε = NBAω sin ωt for rotating coils.
- Apply Lenz’s law to decide whether the induced current is clockwise or anticlockwise.
Common mistakes: confusing the magnetic field B with the flux Φ; forgetting the factor N for a coil; measuring θ from the surface instead of the normal; and dropping the negative sign in direction questions.
Key insight: in electromagnetic induction class 12 notes, deciding which of B, A or θ is changing tells you which formula to use.
How NEET Tests This Chapter
Questions from electromagnetic induction class 12 notes are mostly short numericals plus direction-based conceptual questions:
| Question type | What to revise |
|---|---|
| Changing flux | Induced emf and charge from ΔΦ/Δt; flux through tilted coils |
| Direction | Lenz’s law with moving magnets and coils; Fleming’s right-hand rule |
| Motional emf | Sliding rods (Blv), rotating rods (½Bωl²), force needed to keep a rod moving |
| Inductance | L and M of solenoids, back emf, energy ½LI² |
| AC generator | Peak emf NBAω, effect of changing N, B, A or ω |
Once the notes are revised, practise electromagnetic induction NEET PYQs here, free and with answers.
Key insight: electromagnetic induction class 12 notes questions mostly test one formula plus Lenz’s law for direction.
Electromagnetic Induction Class 12 Notes Summary
Use this checklist for a final run through electromagnetic induction class 12 notes before a test.
- Magnetic flux: Φ = BA cos θ (SI unit: weber); θ measured from the normal.
- Faraday’s law: ε = −N dΦ/dt.
- Lenz’s law: induced current opposes the change in flux; based on conservation of energy.
- Motional emf: ε = Blv for a sliding rod; ½Bωl² for a rotating rod.
- Mutual inductance: ε = −M dI/dt; M = μ₀n₁n₂πr₁²l for coaxial solenoids.
- Self inductance: ε = −L dI/dt; L = μ₀n²Al = μ₀N²A/l.
- Energy in an inductor: U = ½LI².
- Unit of inductance: henry (H).
- AC generator: ε = NBAω sin ωt; peak emf ε₀ = NBAω.
- Transformer: Vs/Vp = Ns/Np = Ip/Is; works only with AC.
